5V RS485 Soil Nitrogen/Phosphorus/Potassium probe for GS1 & GS1-S series (NOT GS1-1DS); Audio plug; Only GS1 after 2022/7/18
U-B_Soil-NPK-Probe. For SP1, GS1 & GS1-S modellerne (dog ikke GS1-1DS). Audio stik og 3m ledning
1.456,25 DKKInkl. moms
På lager
På lager
Fri fragt på ordrer
over 599 DKK
30 dages returret
40 års erfaring
Godkendt af fødevarestyrelsen
Smileyordning
Beskrivelse
Soil NPK Sensor
Monitoring the concentration of N&P&K with embedded RS485 interface
- Measurement range: 0-1999mg/kg
- Measurement accuracy: ±2% F.s
- Resolution: 1mg/kg (mg/l)
- Operating temperature: 5-45°C
- Operating humidity: 5-95% (relative humidity), non-condensing
- Communication port: RS485
- Power supply: 5-30V DC
Tekniske specifikationer
| Power Supply | 5-30V DC |
| Measuring Range | 0-1999mg/kg |
| Measuring Accuracy | ±2%F.s |
| Resolution | 1mg/kg (mg/l) |
| Working Temperature | 5-45℃ |
| Working Humidity | IP 68 |
| Baud Rate | 2400/4800/9600 |
| Communication Methods | RS485 |
| Device supporting | GS1-AETH1RS or GS1-AL4G1RS; Firmware V1.1.1 or above |
